B-9
B-9
53’ Single Expando Support Unit
10 Working Positions
60’ x 23′ Recommended Working Area
Single Phase, 208V, 150 Amps
MU-30
MU-30
46’ 3G Single Expando w/C-Band Uplink
Switcher: Grass Valley K-Frame – 5 M/E 64×48
Audio Board: Calrec Artemis Light (96×120 Analog, 32×32 AES, 320×320 MADI, 64×64 DANTE)
Router:NVision NV8280 242×360 SDI, 20 3G Framesyncs, 170×34 Multiview
Cameras: Grass Valley LDX80 Worldcam
Replay: EVS XT3
MU-29
MU-29
40’ 3G REMI Only Single Expando
Switcher: Grass Valley Karrera – 3.5 M/E 64×48
Audio Board: Calrec Summa (64×64 Analog, 12×12 AES, 320×320 MADI, 64×64 DANTE)
Router: NVision NV8280 192×252 SDI, 20 3G Framesyncs, 160×32 Multiview
Cameras: Grass Valley LDX 86 WorldCam
Replay: EVS XT2+
MU-18
MU-18
53’ 3G Single Expando
Switcher: Grass Valley 3G K-Frame – 5 M/E 104×56
Audio Board: Calrec Artemis (96×96 Analog, 64×64 AES, 256×256 MADI)
Router: Evertz EQX 384×384 SDI, 30 3G Framesyncs, 320×38 Multiview
Cameras: Sony HDC2500 UHD/HDR
Replay: EVS XT4K
MU-17
MU-17
53′ 3G Single Expando
Switcher: Grass Valley 3G K-Frame – 7 M/E 128×64
Audio Board: Calrec Apollo (96×96 Analog, 192×192 AES, 512×512 MADI)
Router: NVision NV8576 396×770 SDI, 45 3G Framesyncs, 342×38 Multiview
Cameras:Grass Valley LDX 86 WorldCam
Replay: EVS XTVia
MU-16
MU-16
53′ UHD 2110 Single Expando
Switcher: Grass Valley 3G K-Frame XP -7 M/E, 94×48 IP, 24×12 SDI
Audio Board: Calrec Argo Q (64×72 Analog, 128×128 AES, 256×256 MADI, 192×192 DANTE)
Router: EVS Strada w/ Cerebrum Control 72 UHD Framesyncs, 480×120 Multiview
Cameras: Sony HDC3500 UHD/HDR
Replay: EVS XTVia
MU-15
MU-15
53′ 3G Single Expando
Switcher: Grass Valley 3G K-Frame – 7 M/E 128×64
Audio Board: Calrec Apollo (96×96 Analog, 192×192 AES, 512×512 MADI)
Router: NVision NV8576 396×770 SDI, 45 3G Framesyncs, 342×38 Multiview
Cameras: Sony HDC3500 UHD/HDR
Replay: EVS XTVia
MU-14
MU-14
53’ 3G Single Expando
Switcher: Grass Valley K-Frame – 9 M/E 176×64
Audio Board: Calrec Apollo (148×148 Analog, 128×128 AES, 512×512 MADI, 64×64 DANTE)
Router: Evertz EQX 256×458 SDI, 30 3G Framesyncs, 304×30 Multiview
Cameras: Sony HDC3500 UHD/HDR
Replay: EVS XTVia
MU-12
MU-12
53’ Single Expando
Switcher: Grass Valley K-Frame – 7 M/E 96×48
Audio Board: Calrec Artemis (96×96 Analog, 128×128 AES, 256×256 MADI)
Router: Evertz EQX 256×458 SDI, 40 3G Framesyncs, 304×30 Multiview
Cameras: Grass Valley LDX 86 WorldCam
Replay: EVS XT3
MU-11
MU-11
53’ 3G Single Expando
Switcher: Grass Valley K-Frame – 7 M/E 96×48
Audio Board: Calrec Apollo (128×128 Analog, 192×192 AES, 512×512 MADI)
Router: Evertz EQX 506×760 SDI, 48 3G Framesyncs, 412×30 Multiview
Cameras: Sony HDC3500 UHD/HDR
Replay: EVS XTVia
