MU-6 53’ Single Expando Overview

The MU-6 53’ Single Expando is a fully loaded, broadcast-grade mobile production unit engineered for large-scale, high-profile live events. Outfitted with an industry-leading 7 M/E Grass Valley switcher, expansive camera and audio systems, and comprehensive routing infrastructure, MU-6 is ideal for live sports, entertainment broadcasts, award shows, and corporate events. Operated by Live Media, a division of Live Media Group, MU-6 delivers unmatched flexibility and performance for complex productions.

Dimensions and Configuration

MU-6 is one of the largest and most technically advanced units in the fleet.

• Overall Length: 78 ft (with tractor)
• Working Footprint: 57 ft long x 22 ft wide (expanded)
• GVW: 80,000 lbs
• Power Requirements: Three Phase, 190–280 Volts, 200 Amps per leg
• Feeder Cable: 200 ft with camlock connectors

Video Production Technology

MU-6 is powered by a Grass Valley K-Frame 3G Switcher with a Kayenne 4-Stripe 35-Button Panel, featuring:

• 7 M/Es
• 90 inputs, 48 outputs
• FlexiKey, Double Take, Chroma Key
• 12 iDPMs, 4 eDPMs, 2D DPM
• Integrated Image Store with movie playback

Replay and Recording:

• (2) EVS XT3 12-Channel LSM Dual User Servers
• (1) EVS XT3 8-Channel LSM Server
• (1) EVS HD LSM-XT3 Spotbox
• (1) EVS Xfile3 with 10G File Network
• (1) EVS X-Hub3
• Lance TDC 100 DDR Controller
• Wired for 8 6-Channel EVS units

Camera System

MU-6 is wired for up to 16 CCUs and features a world-class camera lineup:

• (10) Grass Valley LDX 86/80 Triax WorldCams
• (6) Grass Valley Super XPanders with 7” Viewfinders
• (6) Grass Valley LDK4426 Fiber Triax Converters

Lenses and Accessories:

• (1) Fujinon 101×9.8
• (1) Fujinon 99×8.4
• (1) Fujinon 88×8.8
• (3) Fujinon 72×9.3
• (4) Fujinon 22×7.8
• (2) Fujinon 13×4.5 Wide Angle
• (6) Vinten Vector 70 Pan Heads
• (4) Cartoni Gamma ENG Heads with Tripods
• (2) LPS Cameras

Audio Capabilities

MU-6 features a Calrec Alpha 100 Bluefin Digital Audio Console:

• 72 Faders
• 128×128 Analog
• 80×80 AES
• 256×256 MADI

Additional Audio Equipment:

• (2) Daysequerra Down Mix Encoders
• (2) Daysequerra Up Mix Decoders
• (2) Daysequerra Mono2Stereo Units
• (1) Daysequerra ILM 8 Loudness Meter

Routing and Multiview

Evertz EQX 3G Video Router – 268×236 matrix

• 96×96 Embedding/De-embedding

Evertz EMR Audio Router

• 512×512 MADI, 96×96 AES, 96×192 Analog

Multiview System:

• 25 For-A U/D/C Frame Syncs with Color Correction
• (6) TX Processors with U/D/C
• 200×24 Multiviewer Capacity

Communication Infrastructure

MU-6 features a powerful RTS Adam 168×168 Matrix Intercom system:

• 64 Omneo Channels
• 16 Rvon Channels
• 12 Powered PL Channels
• 16 Additional Powered PL Channels
• (16) Dual Listen BP325 Boxes
• (12) IFB 4030 Boxes
• (16) Single Muff Headsets
• (6) Dual Muff Headsets
• (4) RTS Telephone Interfaces
• (4) QKT Audio Couplers

A/V Support

• (5) HMD26 Announcer Headsets
• (5) Studio Tech Announcer Boxes
• (5) MD46 Stick Microphones
• (6) MKH416 Shotgun Microphones
• (6) MKH8070 Long Shotgun Microphones
• (4) MKH418 Stereo Shotgun Microphones
• (4) 15” SDI Monitors
• (4) 21” SDI Monitors
• (2) LED Light Kits

Cable Inventory

MU-6 includes a robust inventory of cable to support complex remote productions:

• 7,000 ft Triax Cable
• 675 ft SMPTE Fiber
• (3) 150 ft 6-Wire Triax Looms
• 4,000 ft DT12 Audio Mult
• 1,000 ft 6-Pair Audio Snake
• 500 ft 2-Pair Audio Snake
• (4) 125 ft 10-Wire Coax Looms
• (3) 250 ft TAC-12
• (4) 250 ft TAC-6

Why MU-6 Stands Out

MU-6 is designed for major league productions requiring maximum flexibility, capacity, and reliability. With its 7 M/Es, 90 switcher inputs, 16 CCU camera capacity, and massive audio routing and intercom capabilities, MU-6 is the definition of a complete remote broadcast solution. It’s the go-to truck for live sports, network specials, and high-tier entertainment events.

Applications

Perfect for:

• Major professional sports broadcasts
• Red carpet & award shows
• National concerts and festivals
• Live studio-style productions on location

Technical Specifications

For more information or to book MU-6 for your next major broadcast, contact Live Media at 833.933.5483 or email solutions@livemediagroup.com.

Equipment compliment is subject to change to accommodate specific needs.
